PART NUMBER : GDE – 223715A-B
THICKNESS : 0.117in (3.48mm), 0.137 (2.97mm)
Make : General Motors
Year : 1982 – 2009
Trans Unit : 700R4, 4L60E, 4L65E
PROBLEM AREA :
Endplay between the pump stator and the
reverse input drum.
TECH :
These washers, By Greater Dimensions
Engineering, reduces the endplay tolerances’ between the reverse input
drum and pump stator in 700R4, 4L60E and 4L65E transmissions’. The
average amount of endplay tolerances’ found between the reverse input
drum and pump stator is 0.084in, ± 0.005 (2.13mm, ± .128mm). The
factory washer in this transmission is only 0.067in (1.70mm) in
thickness. These washers come in two thicknesses 0.117in (2.97mm)
Mainly for 4L65E and 0.137in (3.43mm) mainly for 700R4, 4L60E By
using one of these thicker washers reduces the endplay tolerances’; by
0.073in (1.85mm) leave about 0.011in (0.28mm) in endplay tolerance.
This corrects the high endplay tolerances’ and increases the life of the
transmission. All measurements where taken using an H-gage and a
Micrometer.
SOLUTION :
“Innovations Outside the Box.”
Contact: support@greaterdimensions.com
Greater Dimensions Engineering
7830 Redfern LN
Bartlett, TN 38133imes New Roman">Bartlett, TN 38133
www.greaterdimensions.com
